Legacy LUT
A Legacy LUT is a precomputed colour lookup table. Each printable colour is paired with a fixed layer-by-layer material recipe, and Lumina Studio selects the closest table entry while previewing an image.
Select a brand and LUT
- Select Legacy LUT under Source Type.
- Select a brand.
- Choose a LUT from the colour-mode groups.
- Generate a preview and inspect key colours, greys, and shadows.
Compatible LUTs under one brand can be selected together. The first selected item remains the primary LUT and the selected tables form one candidate set; no merged file is written to disk. Do not combine tables with incompatible layer counts, layer heights, or material channels.
Refresh and upload
The refresh button beside Brand rereads the LUT directory and its catalogue. It does not modify any LUT file.
Upload accepts .npy, .json, .npz, and .msgpack. After uploading, confirm which LUT is actually selected. A readable
file can still contain incomplete colour-mode, layer, or recipe metadata, so inspect LUT Details if the preview is unexpected.
Dynamic layers
Colour Layers and Layer Height only appear when LUT metadata declares supports_dynamic_layer_count. The store limits the
layer count to 1–20 and the layer height to 0.04–0.20 mm, then invalidates old outputs.
Ordinary legacy LUTs continue to use their stored layer count and height when these controls are not shown.
